VPC Service Controls (VPC-SC) for Databricks on GCP 🔒

VPC Service Controls (VPC-SC) lets you create security perimeters around Google Cloud resources to reduce the risk of data exfiltration and to restrict access to only authorized networks and identities. Databricks supports VPC-SC for both Customer-Managed VPCs (Shared VPC or standalone) and Databricks-managed VPCs.

This guide provides comprehensive configuration instructions for setting up VPC-SC with Databricks on GCP, including identity management, ingress/egress policies, and troubleshooting.

Why Use VPC-SC for Databricks

VPC Service Controls provides defense-in-depth security for Databricks deployments on GCP:

Benefit Description
Perimeter Security Adds an extra layer of security independent of IAM policies (defense-in-depth)
Data Exfiltration Prevention Helps mitigate data exfiltration from services such as Cloud Storage and BigQuery
Restricted Access Ensures resources can be accessed only from authorized networks, devices, or identities
Compliance Helps meet regulatory requirements (HIPAA, PCI-DSS, SOC 2) for data protection
Context-Aware Access Enforces access based on source IP, identity, and device attributes

Important: Use VPC-SC together with IAM, Private Google Access (PGA), and firewall rules for a robust security posture.

Architecture Overview

VPC Service Controls creates security perimeters that protect Google Cloud services and resources:

graph TB
    subgraph "Databricks Control Plane<br/>(Databricks GCP Projects)"
        CP[Control Plane Services]
        ConsumerSA[Consumer SA<br/>db-WORKSPACEID@...]
        DelegateSA[Delegate SA<br/>delegate-sa@...]
        LogSA[Log Delivery SA<br/>log-delivery@...]
    end

    subgraph "VPC Service Controls Perimeter"
        subgraph "Customer GCP Project<br/>(Consumer Project)"
            WS[Databricks Workspace]
            GCS[DBFS Storage<br/>Cloud Storage]
            GCE[Compute Clusters<br/>GCE Instances]
        end
    end

    subgraph "External Services"
        GAR[Artifact Registry<br/>pkg.dev]
        APIs[Google APIs<br/>storage.googleapis.com]
    end

    CP -->|Ingress: Source IPs<br/>Access Level| WS
    ConsumerSA -->|Ingress: Create/Manage| GCS
    DelegateSA -->|Egress: Launch Clusters| GCE
    LogSA -->|Ingress: Deliver Logs| GCS
    GCE -->|Egress: Pull Images| GAR
    GCE -->|Egress: Access Storage| APIs

    style CP fill:#FFE6E6
    style ConsumerSA fill:#E6F3FF
    style DelegateSA fill:#E6F3FF
    style LogSA fill:#E6F3FF
    style WS fill:#E6FFE6
    style GCS fill:#E6FFE6
    style GCE fill:#E6FFE6

Supported Services

For a comprehensive list of services supported by VPC-SC, see:

Key Services for Databricks:

Setting Up Private Connectivity to Google APIs

To restrict Private Google Access within a VPC-SC perimeter to only supported Google APIs and services, hosts must send their requests to the restricted.googleapis.com domain instead of *.googleapis.com.

Restricted Google APIs Configuration

Parameter Value
Domain Name restricted.googleapis.com
IP Range 199.36.153.4/30
Purpose VIP (virtual IP address) range for VPC-SC protected APIs
Announcement Not announced to the Internet (private only)

See Configure Private Google Access for detailed setup instructions.

Quick Overview:

  1. Enable Private Google Access on workspace subnets
  2. Create private DNS zones for googleapis.com pointing to restricted.googleapis.com
  3. Configure VPC routes for 199.36.153.4/30 destination
  4. Set up firewall rules allowing egress to restricted APIs

Understanding Databricks Identities and Projects

Before configuring VPC-SC, it’s essential to understand the various identities and projects involved in Databricks operations.

Key Terms and Definitions

Projects

Term Description Example
Consumer Project Customer-owned GCP project where Databricks workspace is deployed my-company-databricks-prod
Host Project (Shared VPC only) Customer project providing the VPC network my-company-network-host
Service Project (Shared VPC only) Customer project where workspace resources are created Same as Consumer Project
Databricks Regional Control Plane Project Databricks-owned project hosting regional control plane services prod-gcp-us-central1
Databricks Central Service Project Databricks-owned project for central services (workspace creation only) databricks-prod-master
Databricks Artifacts Project Databricks-owned project hosting runtime images databricks-prod-artifacts
Databricks Unity Catalog Project Databricks-owned project for Unity Catalog services uc-useast4

VPC Network

Term Description
Consumer VPC Customer-owned GCP VPC used by Databricks workspace (shared or standalone)

Identities

Term Description Example When Created
Workspace Creator Customer-owned identity (User or Service Account) used to create workspace admin@company.com or ws-creator@project.iam.gserviceaccount.com Before workspace creation
Consumer SA Databricks-created per-workspace service account in control plane project db-1030565636556919@prod-gcp-us-central1.iam.gserviceaccount.com During workspace creation
Delegate SA Databricks regional service account for launching GCE clusters delegate-sa@prod-gcp-us-central1.iam.gserviceaccount.com Pre-existing (regional)
Log Delivery SA Databricks service account for delivering audit logs log-delivery@databricks-prod-master.iam.gserviceaccount.com Pre-existing
Unity Catalog SA Databricks-created service account for Unity Catalog storage access db-uc-storage-UUID@uc-useast4.iam.gserviceaccount.com During Unity Catalog initialization

Control Plane Connectivity

Term Description Reference
Databricks Control Plane IPs Source IP addresses from where requests into your GCP projects originate Databricks IP Addresses by Region

Databricks Service Accounts Reference

Service Account Naming Patterns

Databricks uses several service accounts to manage resources in customer projects:

Service Account Purpose Workspace Type When Used
cluster-manager-k8s-sa@<regional-project>.iam.gserviceaccount.com Legacy GKE cluster management Classic (GKE-based) Legacy only - GKE-based clusters
us-central1-gar-access@databricks-prod-artifacts.iam.gserviceaccount.com Access to Databricks runtime images Classic (GKE-based) Legacy only - GKE-based clusters
delegate-sa@prod-gcp-[GEO]-[REGION].iam.gserviceaccount.com Launch and manage GCE-based clusters Classic (GCE-based) Current - GCE-based clusters
db-[WORKSPACEID]@[databricks-project].iam.gserviceaccount.com Per-workspace resource management All workspace types Always - Created at workspace creation
log-delivery@databricks-prod-master.iam.gserviceaccount.com Deliver audit logs to customer storage All (if audit logs enabled) When audit logging configured
db-uc-storage-UUID@<uc-regional-project>.iam.gserviceaccount.com Unity Catalog storage access Unity Catalog workspaces When Unity Catalog initialized

Databricks Project Numbers

A list of Databricks-owned GCP project numbers is available at: Databricks Supported Regions

Required for VPC-SC Configuration: You’ll need these project numbers when defining ingress sources and egress destinations in perimeter policies.

Identity Usage Matrix

Understanding which identities are used for ingress (calls into customer projects) and egress (calls out to Databricks projects):

Identity Type Example Used For Traffic Direction VPC-SC Policy Impact
Workspace Creator User or SA admin@company.com Workspace creation Ingress into customer project Must be allowed in Access Level
Consumer SA SA db-WORKSPACEID@prod-gcp-us-central1.iam.gserviceaccount.com Workspace operation, DBFS management Ingress into customer project Created at WS creation - use ANY_IDENTITY
Delegate SA SA delegate-sa@prod-gcp-us-central1.iam.gserviceaccount.com Launch GCE clusters Egress from customer project Must be in egress policy
Log Delivery SA SA log-delivery@databricks-prod-master.iam.gserviceaccount.com Deliver audit logs Ingress into customer project Must be in ingress policy
GKE Manager SA (Legacy) SA cluster-manager-k8s-sa@prod-gcp-us-central1.iam.gserviceaccount.com Legacy GKE cluster access to control plane Egress from customer project Legacy only - GKE workspaces
GAR Access SA (Legacy) SA us-central1-gar-access@databricks-prod-artifacts.iam.gserviceaccount.com Legacy GKE cluster access to runtime images Egress from customer project Legacy only - GKE workspaces

VPC-SC Configuration Workflow

The VPC-SC configuration follows different patterns depending on the workspace lifecycle stage:

sequenceDiagram
    participant User as Workspace Creator
    participant ACM as Access Context Manager
    participant Perimeter as VPC-SC Perimeter
    participant Project as Consumer Project
    participant CP as Databricks Control Plane

    Note over User,CP: Phase 1: Workspace Creation

    User->>ACM: 1. Create Access Level<br/>(Allow Control Plane IPs)
    User->>Perimeter: 2. Create Perimeter (Dry-Run Mode)<br/>with create-ws-ingress policy
    User->>Perimeter: 3. Test in Dry-Run Mode
    User->>Perimeter: 4. Enforce Perimeter
    User->>CP: 5. Create Databricks Workspace
    CP->>Project: 6. Create Consumer SA<br/>(db-WORKSPACEID@...)
    CP->>Project: 7. Create DBFS Buckets
    Note over Project: Workspace is now created

    Note over User,CP: Phase 2: Post-Workspace Operation

    User->>Perimeter: 8. Update Perimeter<br/>Replace with ingress + egress policies
    User->>Perimeter: 9. Test in Dry-Run Mode
    User->>Perimeter: 10. Enforce Updated Perimeter
    Note over Project,CP: Workspace operational with full policies

Configuration Phases

Phase Policy Files Purpose When to Use
Workspace Creation create-ws-ingress.yaml Allow workspace creation and initial resource setup Before creating workspace
Post-Creation Operation ingress.yaml + egress.yaml Full operational policies for running workspaces After workspace is created
Least Privilege Workspaces (LPW) Special policies (see separate folder) Highly restricted environments requiring allowlisting Special use case - not common

VPC-SC Policy Files

Before proceeding, update all policy YAML files with your relevant project numbers, identities, and IP ranges.

Available Policy Templates

Policy File Purpose Usage Stage Key Features
create-ws-ingress.yaml Workspace creation ingress policy During workspace creation Allows Control Plane to create Consumer SA and DBFS buckets
ingress.yaml Operational ingress policy After workspace creation Allows ongoing workspace management and log delivery
egress.yaml Operational egress policy After workspace creation Allows cluster nodes to access Control Plane and Artifact Registry
LPW policies Least privilege workspace policies Special use case Highly restricted - separate folder (not common)

Why Use ANY_IDENTITY for Consumer SA?

At workspace creation, Databricks automatically creates a per-workspace service account:

DBFS Buckets Created:

Consumer SA Format:

Why ANY_IDENTITY is Required: Since the Consumer SA is automatically generated during workspace creation (with workspace ID unknown beforehand), we cannot pre-configure the specific service account in the ingress policy. Therefore, we use ANY_IDENTITY with source project restrictions:

sources:
  - accessLevel: accessPolicies/[POLICY_ID]/accessLevels/databricks_control_plane_ips
identityType: ANY_IDENTITY  # Required because Consumer SA doesn't exist yet

This still requires requests to originate from:

  1. ✅ Databricks Control Plane projects (project number restrictions)
  2. ✅ IPs matching Access Level (Control Plane NAT IPs)
  3. ❌ NOT arbitrary sources

Configuration Steps

Prerequisites

Before configuring VPC-SC, ensure you have:

Step 1: Create Access Context Manager Access Level

Create an Access Level that allows traffic from Databricks Control Plane IP addresses:

# Get your Access Context Manager policy ID
ACCESS_POLICY_ID=$(gcloud access-context-manager policies list --format="value(name)")

# Create Access Level allowing Databricks Control Plane IPs
gcloud access-context-manager levels create databricks_control_plane_ips \
  --title="Databricks Control Plane IPs" \
  --basic-level-spec=access-level-spec.yaml \
  --policy=$ACCESS_POLICY_ID

access-level-spec.yaml:

- ipSubnetworks:
  # Replace with your region's Control Plane NAT IPs
  - "34.138.66.176/32"    # Example: us-east1 control plane IP 1
  - "34.73.198.113/32"    # Example: us-east1 control plane IP 2
  # Add all control plane IPs for your region
  # See: https://docs.gcp.databricks.com/resources/supported-regions.html#ip-addresses-and-domains

Step 2: Create Service Perimeter (Dry-Run Mode)

For Workspace Creation, start with create-ws-ingress.yaml:

# Create perimeter in DRY-RUN mode first
gcloud access-context-manager perimeters dry-run create databricks-perimeter \
  --title="Databricks VPC-SC Perimeter" \
  --resources=projects/[CONSUMER_PROJECT_NUMBER] \
  --restricted-services=storage.googleapis.com,compute.googleapis.com \
  --ingress-policies=create-ws-ingress.yaml \
  --policy=$ACCESS_POLICY_ID

Step 3: Test in Dry-Run Mode

Monitor VPC-SC logs to verify the perimeter allows required traffic:

# Check VPC-SC audit logs for violations
gcloud logging read "protoPayload.metadata.dryRun=true AND protoPayload.metadata.vpcServiceControlsUniqueId:*" \
  --limit=50 \
  --format=json

Expected: No violations for legitimate Databricks traffic. If violations occur, adjust the policy.

Step 4: Enforce Perimeter

After validating in dry-run mode:

# Enforce the perimeter
gcloud access-context-manager perimeters dry-run enforce databricks-perimeter \
  --policy=$ACCESS_POLICY_ID

Step 5: Create Databricks Workspace

Now create your Databricks workspace using the UI, CLI, or Terraform. The VPC-SC perimeter will allow the Control Plane to:

Step 6: Update Perimeter for Post-Creation Operation

After workspace creation succeeds, update the perimeter with full operational policies:

# Update perimeter with ingress + egress policies
gcloud access-context-manager perimeters update databricks-perimeter \
  --set-ingress-policies=ingress.yaml \
  --set-egress-policies=egress.yaml \
  --policy=$ACCESS_POLICY_ID \
  --dry-run

Step 7: Test Updated Policies in Dry-Run

Again, monitor logs for violations:

gcloud logging read "protoPayload.metadata.dryRun=true" --limit=50

Step 8: Enforce Updated Perimeter

# Enforce updated policies
gcloud access-context-manager perimeters dry-run enforce databricks-perimeter \
  --policy=$ACCESS_POLICY_ID

Policy Structure Explained

Ingress Policy Structure

Ingress policies control traffic into your consumer project from Databricks services:

- ingressFrom:
    sources:
      # Access Level: Only allow from Control Plane IPs
      - accessLevel: accessPolicies/[POLICY_ID]/accessLevels/databricks_control_plane_ips
    # Identity: Use ANY_IDENTITY because Consumer SA doesn't exist at creation
    identityType: ANY_IDENTITY
  ingressTo:
    # Target: Your consumer project resources
    resources:
      - projects/[CONSUMER_PROJECT_NUMBER]
    # Operations: What APIs and methods are allowed
    operations:
      - serviceName: storage.googleapis.com
        methodSelectors:
          - method: "*"  # Allow all storage operations
      - serviceName: compute.googleapis.com
        methodSelectors:
          - method: "*"  # Allow all compute operations

Key Components:

Egress Policy Structure

Egress policies control traffic from your consumer project to Databricks services:

- egressFrom:
    # Identity: Service accounts in your project making outbound calls
    identities:
      - serviceAccount:db-[WORKSPACEID]@prod-gcp-us-central1.iam.gserviceaccount.com
  egressTo:
    # Target: Databricks projects
    resources:
      - projects/[DATABRICKS_CONTROL_PLANE_PROJECT_NUMBER]
      - projects/[DATABRICKS_ARTIFACTS_PROJECT_NUMBER]
    # Operations: What APIs the cluster can access
    operations:
      - serviceName: storage.googleapis.com
        methodSelectors:
          - method: "*"
      - serviceName: artifactregistry.googleapis.com
        methodSelectors:
          - method: "*"

Key Components:

gcloud Command Reference

Action Command
List Access Policies gcloud access-context-manager policies list --format=yaml
Create Access Level gcloud access-context-manager levels create [LEVEL_NAME] --basic-level-spec=[FILE] --policy=[POLICY_ID]
Create Perimeter (Dry-Run) gcloud access-context-manager perimeters dry-run create [PERIMETER_NAME] --title="[TITLE]" --resources=projects/[PROJECT_NUM] --ingress-policies=[FILE] --policy=[POLICY_ID]
Enforce Perimeter gcloud access-context-manager perimeters dry-run enforce [PERIMETER_NAME] --policy=[POLICY_ID]
Update Perimeter gcloud access-context-manager perimeters update [PERIMETER_NAME] --set-ingress-policies=[FILE] --set-egress-policies=[FILE] --policy=[POLICY_ID]
List Perimeters gcloud access-context-manager perimeters list --format=yaml --policy=[POLICY_ID]
Describe Perimeter gcloud access-context-manager perimeters describe [PERIMETER_NAME] --policy=[POLICY_ID]
Delete Perimeter gcloud access-context-manager perimeters delete [PERIMETER_NAME] --policy=[POLICY_ID]

Sample Commands: See gcloud-run-book.txt for complete examples.

Validation and Testing

Validation Checklist

Test Workspace Creation

  1. Create Access Level and Perimeter with create-ws-ingress.yaml
  2. Enforce perimeter in dry-run first, then production
  3. Attempt to create Databricks workspace via UI or API
  4. Verify workspace creation succeeds
  5. Check that DBFS buckets are created
  6. Confirm Consumer SA exists in IAM

Test Operational Access

After updating to ingress + egress policies:

  1. Launch a test cluster
  2. Run notebook accessing Cloud Storage:
    # Test DBFS access
dbutils.fs.ls("dbfs:/")

# Test external bucket access
dbutils.fs.ls("gs://your-bucket/")
  3. Test package installation (pulls from Artifact Registry):
    %pip install pandas
  4. Monitor VPC-SC logs for violations

Check VPC-SC Logs

# Check for VPC-SC violations
gcloud logging read "protoPayload.metadata.@type=type.googleapis.com/google.cloud.audit.VpcServiceControlAuditMetadata" \
  --limit=50 \
  --format=json

# Check for denied requests
gcloud logging read "protoPayload.metadata.securityPolicyInfo.vpcServiceControlsUniqueId:* AND protoPayload.authorizationInfo.granted=false" \
  --limit=50

Troubleshooting

Common Issues

Issue Symptom Root Cause Solution
Workspace creation fails “VPC Service Controls violation” error Ingress policy not allowing Control Plane access Verify Access Level includes all Control Plane IPs for your region
Consumer SA creation blocked Workspace creation fails at resource setup identityType not set to ANY_IDENTITY Update ingress policy to use identityType: ANY_IDENTITY
DBFS bucket access denied “Access Denied” when accessing dbfs:/ Consumer SA not in ingress policy or missing storage API permissions Verify storage.googleapis.com in ingress policy operations
Cluster launch fails Cluster stuck in PENDING state Egress policy not allowing access to Control Plane Add egress policy with delegate-sa identity and Control Plane project
Runtime image pull fails Cluster fails with image download error Egress policy not allowing Artifact Registry access Add artifactregistry.googleapis.com to egress operations
Log delivery fails Audit logs not appearing in bucket Log Delivery SA not in ingress policy Add log-delivery@databricks-prod-master.iam.gserviceaccount.com to ingress identities
Policy update fails “Cannot update enforced perimeter” Trying to update enforced policy directly Use dry-run mode first: --dry-run, test, then enforce

Debug Commands

# Get Access Context Manager policy ID
gcloud access-context-manager policies list --format="value(name)"

# List all access levels
gcloud access-context-manager levels list --policy=[POLICY_ID]

# Describe specific access level
gcloud access-context-manager levels describe databricks_control_plane_ips --policy=[POLICY_ID]

# List all perimeters
gcloud access-context-manager perimeters list --policy=[POLICY_ID]

# Describe specific perimeter
gcloud access-context-manager perimeters describe databricks-perimeter --policy=[POLICY_ID]

# Check VPC-SC audit logs
gcloud logging read "protoPayload.metadata.@type=type.googleapis.com/google.cloud.audit.VpcServiceControlAuditMetadata" \
  --limit=50 \
  --format=json

# Check for specific project violations
gcloud logging read "resource.labels.project_id=[PROJECT_ID] AND protoPayload.metadata.vpcServiceControlsUniqueId:*" \
  --limit=50

VPC-SC Violation Log Analysis

When investigating VPC-SC violations, look for these fields in audit logs:

{
  "protoPayload": {
    "metadata": {
      "@type": "type.googleapis.com/google.cloud.audit.VpcServiceControlAuditMetadata",
      "vpcServiceControlsUniqueId": "...",
      "securityPolicyInfo": {
        "servicePerimeterName": "...",
        "violationReason": "NO_MATCHING_ACCESS_LEVEL"
      }
    }
  }
}

Common Violation Reasons:

Best Practices

Security Best Practices

Practice Description Benefit
Always use dry-run mode first Test policies before enforcement Prevents breaking production workspaces
Use Access Levels for IP restrictions Define allowed source IPs in Access Levels Restricts access to known Control Plane IPs
Principle of least privilege Only allow minimum required APIs and methods Reduces attack surface
Regular policy reviews Audit VPC-SC policies quarterly Ensures policies remain aligned with security requirements
Monitor VPC-SC logs Set up alerts for VPC-SC violations Detects unauthorized access attempts
Use restricted Google APIs Configure restricted.googleapis.com Limits to VPC-SC compliant services only
Document all exceptions Maintain documentation for policy decisions Simplifies audits and policy updates

Operational Best Practices

Practice Description
Separate policies for creation and operation Use create-ws-ingress.yaml during creation, then switch to full policies Simplifies workspace creation process
Test in non-production first Validate policies in dev/test environments Catches issues before production impact
Use Infrastructure as Code Manage VPC-SC with Terraform Ensures reproducibility and version control
Staged rollout Deploy to one workspace, validate, then expand Reduces risk of widespread issues
Maintain runbook Document troubleshooting steps Speeds up incident resolution
Subscribe to Databricks updates Monitor for changes in IP addresses or service accounts Keeps policies current

Configuration Best Practices

Practice Recommendation
Project organization Use separate projects for dev/test/prod with separate perimeters
Access Level naming Use descriptive names like databricks_[region]_control_plane_ips
Policy versioning Store policy YAML files in Git with clear versioning
Perimeter scope Include all related projects in perimeter (host + service projects for Shared VPC)
Update process Establish change management process for policy updates

Integration with Other Security Controls

Combined with Private Google Access

VPC-SC works seamlessly with Private Google Access:

graph LR
    Cluster[Databricks Cluster] -->|1. DNS Query| DNS[Private DNS<br/>googleapis.com]
    DNS -->|2. Resolve to| VIP[Restricted VIP<br/>199.36.153.4/30]
    VIP -->|3. Firewall Check| FW[Firewall Rules<br/>Allow 199.36.153.4/30]
    FW -->|4. VPC-SC Check| SC[VPC Service Controls<br/>Perimeter]
    SC -->|5. Access Allowed| API[Google APIs<br/>VPC-SC Protected]

    style Cluster fill:#E6F3FF
    style DNS fill:#FFE6E6
    style VIP fill:#FFE6E6
    style FW fill:#FFE6E6
    style SC fill:#E6FFE6
    style API fill:#E6FFE6

Benefits of Combined Approach:

  1. DNS Layer: Private DNS ensures resolution to restricted endpoints
  2. Network Layer: Firewall rules limit egress destinations
  3. API Layer: VPC-SC enforces security perimeters
  4. Identity Layer: IAM controls who can perform operations

See Configure Private Google Access for PGA setup.

Combined with VPC Firewall Rules

VPC-SC complements firewall rules for defense-in-depth:

Layer Control Enforcement Point What It Protects
Network VPC Firewall Rules IP/Port level Controls network connectivity by IP and port
API VPC Service Controls API level Controls access to Google Cloud APIs and services
Identity IAM Policies Resource level Controls who can perform actions on resources

See Lock Down VPC Firewall Rules for firewall configuration.

Configuration Checklist

Pre-Configuration

Step Task Status
1 Identify Databricks Control Plane IPs for your region ☐
2 Identify Databricks project numbers for your region ☐
3 Identify your Consumer Project number(s) ☐
4 Verify IAM permissions for VPC-SC configuration ☐
5 Configure Private Google Access and DNS ☐

Workspace Creation Phase

Step Task Status
6 Get Access Context Manager policy ID ☐
7 Create Access Level with Control Plane IPs ☐
8 Update create-ws-ingress.yaml with your values ☐
9 Create Service Perimeter in dry-run mode ☐
10 Test dry-run and review logs ☐
11 Enforce Service Perimeter ☐
12 Create Databricks workspace ☐
13 Verify workspace creation succeeds ☐
14 Verify Consumer SA and DBFS buckets created ☐

Post-Creation Phase

Step Task Status
15 Update ingress.yaml with your values ☐
16 Update egress.yaml with your values and workspace-specific SA ☐
17 Update perimeter with ingress + egress policies (dry-run) ☐
18 Test dry-run and review logs ☐
19 Enforce updated perimeter ☐
20 Launch test cluster ☐
21 Verify cluster can access DBFS ☐
22 Verify cluster can pull runtime images ☐
23 Monitor VPC-SC logs for violations ☐
24 Document any policy adjustments made ☐

References

Summary

✅ Recommended VPC Service Controls Configuration for Databricks on GCP:

  1. Use two-phase approach: Create workspace with create-ws-ingress.yaml, then update to full ingress.yaml + egress.yaml
  2. Always start with dry-run mode: Test policies before enforcement to avoid breaking workspaces
  3. Use Access Levels: Restrict access to Databricks Control Plane IPs only
  4. Use ANY_IDENTITY for Consumer SA: Required because Consumer SA is created during workspace creation
  5. Configure restricted Google APIs: Use restricted.googleapis.com (199.36.153.4/30) with VPC-SC
  6. Monitor VPC-SC logs: Set up alerts for violations and review regularly
  7. Document all policies: Maintain clear documentation for policy decisions and updates
  8. Test thoroughly: Validate in non-production before applying to production workspaces

VPC Service Controls provides an essential security layer for Databricks on GCP, working together with IAM, Private Google Access, and VPC firewall rules to create a comprehensive defense-in-depth security architecture.
